DiversiTech PRO CP -16 - Asurity Pro Condensate Pump (120V, 16' Lift)
DiversiTech PRO CP -16 - Asurity Pro Condensate Pump (120V, 16' Lift)
The PRO CP-16 120V condensate pump from DiversiTech is designed for dependable removal of condensate in residential and light commercial HVAC/R systems. It is commonly used with air conditioners, high-efficiency furnaces, fan coils, and other ducted HVAC equipment where gravity drainage is not available.
This general-purpose condensate pump delivers a maximum lift height of 16 feet and a flow rate of up to 72 gallons per hour, providing reliable performance across a wide range of installations. It is rated to handle condensate temperatures up to 160°F, making it suitable for both cooling and heating applications.
The PRO CP-16 features a compact 0.5-gallon reservoir with four inlet ports for flexible installation options. Sturdy metal hang tabs allow secure mounting, while the removable check valve helps prevent backflow and simplifies servicing. The pump is UL listed for safety and comes factory-equipped with a standard NEMA 5-15 plug for 120-volt power connections.
This 120V version is ideal for standard residential electrical setups where a durable, easy-to-install condensate pump is required.
| Category | Specification | Category | Specification |
|---|---|---|---|
| Model | PRO CP-16 | Application | General purpose condensate pump |
| System Type | Ducted | UL Listed | Yes |
| Voltage | 120 VAC | Frequency | 60 Hz |
| Amperage | 1.9 Amps | Motor Output | 1/50 HP |
| Plug Type | NEMA 5-15 | Color | Black / Red |
| Maximum Lift Height | 16 ft | Maximum Flow Rate | 72 GPH |
| Flow Rate @ 10 ft Lift | 48 GPH | Max Condensate Temp | 160°F |
| Tank Capacity | 0.5 gallon | Number of Inlets | 4 |
| Discharge Line Size | 3/8 inch | Check Valve | Removable |
| Self-Cleaning | No | High Level Switch | No |
| Floatless Sensor | No | Mounting | Metal hang tabs |
| Width | 6.5 inches | Depth | 12.25 inches |
| Height | 7.5 inches | Weight | 5.35 lbs |
| UPC | 0095247173006 |
The PRO CP-16 120V condensate pump from DiversiTech is a dependable, general-purpose solution for removing condensate from residential and light commercial HVAC/R systems. It is commonly used with air conditioners, high-efficiency furnaces, fan coil units, and other ducted HVAC equipment where gravity drainage is not available or practical.
Designed for consistent performance, this 120-volt condensate pump provides a maximum lift height of up to 16 feet and a maximum flow rate of 72 gallons per hour. At a 10-foot lift, the pump delivers 48 GPH, making it well suited for a wide range of installations. It is rated to handle condensate temperatures up to 160°F, allowing it to operate reliably in both cooling and heating applications without performance issues.
The PRO CP-16 features a compact 0.5-gallon reservoir and includes four inlet ports to accommodate multiple drain connections. This flexible inlet design makes installation easier in tight mechanical spaces and retrofit applications. The unit is equipped with sturdy metal hang tabs that allow for secure mounting on walls or equipment, helping ensure long-term stability and reduced vibration during operation.
To help prevent backflow and simplify maintenance, the pump includes a removable check valve. The pump operates on standard 120 VAC power and comes factory-installed with a NEMA 5-15 plug, making it compatible with typical residential electrical outlets. With a 1/50 HP motor and a current draw of 1.9 amps, the PRO CP-16 delivers efficient performance without excessive power consumption.
The pump is UL listed for safety and reliability and is intended for use in ducted HVAC/R systems. Its durable construction and proven design make it a practical choice for contractors looking for a reliable condensate pump that installs easily and performs consistently over time.
Whether used in new installations or as a replacement condensate pump, the DiversiTech PRO CP-16 120V offers a balance of performance, durability, and installation flexibility for everyday HVAC condensate management needs.
