Honeywelll Q624A1014 - 120 VAC 50/60 Hz Gas ignition Transformer
Honeywelll Q624A1014 - 120 VAC 50/60 Hz Gas ignition Transformer
Ignite gas pilots with spark gaps up to 1/4 in. (6.5 mm).
Reliable light off with 15,000 peak voltage.
Prevent detection of the ignition spark when properly applied in a flame detection system with the C7027, C7035 or C7044 Minipeeper Ultraviolet Flame Detector.
For use only in interrupted ignition applications.
Mount in same space used by conventional ignition transformer.
Light weight, 3 lbs. (1.4 kg) versus 8-1/2 lbs. (3.9 kg) for standard transformers.
Application: Gas Ignition Transformer
Voltage: 120v
Frequency: 50-60 Hz
Operating Humidity: 95% RH
Ambient Temperature: -40 to 125F
Height (Inches): 6.75"
Width: 4-1/4"
Depth (Inches): 3"
