Honeywelll T775A2009 - Electronic Temperature Controller with 1 Temperature Input, 1 SPDT Relay, 1 Sensor Included
Honeywelll T775A2009 - Electronic Temperature Controller with 1 Temperature Input, 1 SPDT Relay, 1 Sensor Included
Application: Electronic Remote Temperature
Sensor Inputs: 1
Output: SPDT, Relay
Voltage: 240v, 24v, 120v
Hertz: 60, 50
Contact Ratings 24v: 10.0 A Resistive
Contact Ratings 120v: 58.8 ALR, 125 VA Pilot Duty, 9.8 AFL, 1/2 hp
Contact Ratings 240v: 1/2 hp, 4.9 AFL, 125 VA Pilot Duty, 29.4 ALR
Height (Inches): 8.15625"
Width (Inches): 4-13/32"
Depth (Inches): 2-15/16"
Sensor Type: 1097 ohm @ 77 F PTC, 50021579-001
Max Dist To Sensor: Up to 1000 ft
Bulb Size:, 1/4" x 2"
Max Temp (F):, 248°F
Temperature Range (F): -40°F to 248°F
Min Temp (F): -40°F
Accuracy: +/-1° at 77°F
Throttling Range: 1°F to 150°F
Ambient Operating Temperature: -40°F to 125°F @ 50 Hz, -40°F to 140°F @ 60 Hz
Replaces: T775A1001
Features: NEMA-1 Enclosure
