The ICM203B Delay on Break Timer by ICM Controls offers reliable compressor protection by preventing short cycling in HVAC and refrigeration systems. Designed for fixed-delay applications, the ICM203B activates a preset delay period after power interruption or thermostat signal loss, ensuring the compressor cannot restart too quickly—safeguarding it from potential damage.

Ideal for contractors and system installers seeking a quick, no-adjustment-required solution, the ICM203B supports a universal input voltage range from 18–240 VAC and installs with a simple 2-wire hookup. This compact, solid-state timer is perfect for systems where consistent timing is critical.

Key Features:

• Fixed delay on break time (model-specific, typically 5 minutes)

• Protects compressors from rapid short cycling

• Universal voltage: 18–240 VAC

• Simple 2-wire installation

• Durable solid-state design

• Compact and easy to install

Specifications:

• Input Voltage: 18–240 VAC

• Fixed Delay: Factory preset (typically 5 minutes)

• Current Rating: 1.5A (15A in-rush)

• Weight: 0.1 lbs

• Dimensions: 2" L × 2" W × 1.25" H

Replaces:

• A-1: EAC-501-ADJ

• Diversified: AC-503

• MARS: 32001, 32387, 32392

• Robertshaw: 3310-072

• Supco: TD72, TD73

• Wagner / DiversiTech: ADB-1

The ICM203B is a dependable, plug-and-play solution to extend the life of your compressor. Available now at Beenimax.com.
