ICM-ICM517A — Single-Phase Type 2 Surge Protective Device (120/240V, NEMA 4X)
Protect HVAC systems and household electronics from damaging voltage spikes with the ICM-ICM517A.
This single-phase, Type 2 surge protective device (SPD) provides whole-equipment protection at 120/240 VAC and is housed in a rugged NEMA 4X enclosure for reliable indoor/outdoor use. With a high surge capacity and compact footprint, it’s a professional-grade safeguard for air conditioners, heat pumps, mini-splits, well pumps, refrigerators, and more.
Key Features
- Whole-equipment protection for 120/240V single-phase systems; ideal at service disconnects or sub-panels
- High surge capacity with robust, fast-clamping protection against transient overvoltage
- NEMA 4X enclosure: UV-resistant and corrosion-resistant for harsh environments
- Protection modes: L-L, L-N, L-G, N-G
- Quick installation with 3/4" conduit connection and compact design
- At-a-glance status via green indicator (suppression present)
- Field-proven design: “A” revision of the ICM517 for added durability
Technical Specifications
- Service Voltage: 120/240 VAC, single phase (60 Hz)
- Device Type: Type 2 SPD (equipment/branch panel)
- Protection Modes: L-L, L-N, L-G, N-G
- Enclosure Rating: NEMA 4X (indoor/outdoor)
- Conduit: 3/4"
- Status Indicator: Green LED (suppression present)
Applications
- Central AC and heat pump condensers
- Mini-split systems and air handlers
- Refrigeration equipment
- Well and sump pumps
- General residential and light commercial electronics
What’s in the Box
- ICM-ICM517A surge protective device
- Mounting hardware and installation instructions
- (Professional installation by a licensed electrician/HVAC technician is recommended.)
Warranty
- Limited lifetime product warranty with connected-equipment coverage per manufacturer policy.
- See enclosed documentation for full terms and conditions.
120/240 VAC, single phase, max surge current 100,000 amps, max energy disptn 840 joules in superior waterproof / fireproof enclosure
