ICM-ICM715 ECM to PSC Motor Controller – Reliable HVAC Replacement
Product Overview
The ICM-ICM715 is a cost-effective ECM-to-PSC motor controller that allows technicians and contractors to replace expensive electronically commutated motors (ECMs) with more affordable permanent split capacitor (PSC) motors. Designed with durability and efficiency in mind, it provides a reliable solution for HVAC systems while reducing replacement and repair costs.
Key Benefits
- Affordable ECM Replacement: Replaces costly ECM blower motors with PSC motors while maintaining consistent system performance.
- Wide Compatibility: Supports constant torque ECM blower motors, such as X13 or SelecTech, up to 1 horsepower.
- Simple Speed Selection: Provides one fixed speed for PSC motors, ensuring straightforward setup and operation.
- Selectable Delay Feature: Offers a 3-minute delay on break or a 5-second test mode for flexible system control.
- Technician-Friendly Design: Compact, easy to install, and built for quick field replacement.
Technical Specifications
- Motor Voltage: 120 VAC or 208–240 VAC
- Input Control Voltage: 24 VAC
- Input Frequency: 50–60 Hz
- Maximum Blower Horsepower: 1 HP
- Dimensions: Approx. 4.3″ × 3.1″
- OEM Replacement For: QwikSwap X1
Applications
The ICM-ICM715 is ideal for residential and light commercial HVAC systems that require an ECM replacement solution without the high cost of OEM motors. It provides consistent blower motor control, reduces equipment expenses, and simplifies long-term maintenance.
ECM to PSC Motor Controller , OEM Replacement QuikSwap X1
| Package Quantity | 1 Item |
|---|---|
