Lennox 54G57 - (54G5701) Timer Delay Relay, ON 1 Sec, OFF 8 Sec, 24 Volts
The Lennox 54G57 (part number 54G5701) is a reliable and compact timer delay relay designed for precise control in HVAC systems. This module features a timed ON delay of 1 second and an OFF delay of 8 seconds, making it ideal for staged control of components where sequencing is critical. Operating at 24 volts, it integrates seamlessly into low-voltage HVAC circuits commonly found in residential and light commercial units.
Engineered to provide dependable timing functionality, the 54G57 helps improve system efficiency and protects components from rapid cycling or undesired startup overlap. It is commonly used for fan control, blower sequencing, or compressor delay applications where timing precision is essential.
Key Features:
- Model: 54G57 / 54G5701
- Function: Timer delay relay
- ON Delay: 1 second
- OFF Delay: 8 seconds
- Control Voltage: 24 VAC
- Application: Fan motors, blowers, compressors, and HVAC sequence timing
- Compact Design: Easy integration into control panels and enclosures
- Reliable Operation: Minimizes component stress and improves system longevity
Applications:
The Lennox 54G57 is used across a variety of Lennox HVAC systems and compatible equipment where timing control between system components is necessary to maintain optimal performance and prevent short cycling.
The Lennox 54G57 is used across a variety of Lennox HVAC systems and compatible equipment where timing control between system components is necessary to maintain optimal performance and prevent short cycling.
Ensure consistent, efficient system operation with the Lennox 54G57 timer delay relay — a trusted solution for precision HVAC timing control.
