Lennox 60L25 Condenser Fan Motor 60L2501 is a genuine OEM 1 HP commercial HVAC replacement motor designed for reliable condenser operation in three phase systems. Engineered for 460 VAC 3 phase 60 Hz power supply and rated at 1140 RPM, this vertical mount motor delivers consistent airflow and efficient heat rejection for commercial air conditioning equipment.

Manufactured in Mexico to Lennox factory specifications, this 56 frame motor features CCWLE rotation and a 3.3 inch shaft length for proper fit and direct replacement compatibility. With a gross weight of 40 lbs, the motor is built for durability in demanding rooftop and commercial condenser applications.

This OEM Lennox condenser fan motor helps maintain optimal system efficiency, protects compressor performance, and restores proper airflow in commercial HVAC units. Ideal for service technicians and contractors requiring an exact-fit factory replacement part.

Product Specifications

Brand: Lennox
Catalog Number: 60L25
Model Number: 60L2501
EAN / UPC: 66255122320
Motor Type: 3 Phase Condenser Fan Motor
Horsepower: 1 HP
Voltage: 460 VAC
Phase: 3 Phase
Frequency: 60 Hz
Speed: 1140 RPM
Frame Size: 56
Rotation: CCWLE
Shaft Length: 3.3 Inch
Mounting Position: Vertical
Gross Weight: 40 lb
Country of Origin: Mexico
Base Unit of Measure: Each

Replacement History

60L25
60L2501
