Mars C1158 - 1Hp,1Ph,115/208-230V,1725RPM

Brand:
Reviews (0)
SKU
C1158
Mars C1158 - 1Hp,1Ph,115/208-230V,1725RPM

Mars C1158 - 1Hp,1Ph,115/208-230V,1725RPM

SKU
C1158
Brand:
Reviews (0)
$506.55
Out of stock

SPECIAL REQUEST

Important Notice:

This is a special order item and will ship with a minimum lead time of 14 days.

Special order items are non-returnable and cannot be canceled once placed.

Please note: Pricing is not final and will be confirmed after we contact you.

No. of Poles: 4
Motor Type: Capacitor Start Induction Run
Enclosure: Drip Proof
HP (Max.): 1
Voltage: 115/208-230
Mounting: Resilient Base
Speeds: 1
Hz: 60
Rotation: CW/CCW
RPM Range: 1725
NEMA Frame Size: 56
Phase: Single
Standards: UR/CSA
FLA: 14.7/7.2-7.4
Bearing: Ball
Thermal Protection: Auto
Ambient Deg C: 40
Ins. Class: B
Shaft Dia. (in.): 5/8
Capacitor Included: Yes
Shaft Length (in.): 1.88
Service Factor: 1.15
Duty: Continuous
Weight: 28.8500 lbs
Harmonized Tariff Code: 8501406040
