Mars P190 - 1 HP 200-230/460V 1075RPM COND

Brand:
Reviews (0)
SKU
P190
Mars P190 - 1 HP 200-230/460V 1075RPM COND

Mars P190 - 1 HP 200-230/460V 1075RPM COND

SKU
P190
Brand:
Reviews (0)
$749.00
Out of stock

SPECIAL REQUEST

Important Notice:

This is a special order item and will ship with a minimum lead time of 14 days.

Special order items are non-returnable and cannot be canceled once placed.

Please note: Pricing is not final and will be confirmed after we contact you.

No. of Poles: 6
Motor Type: PSC
Enclosure: Open Enclosed
HP (Max.): 1
Voltage: 200-230/460
Mounting: Thru Bolt or Belly Band
Speeds: 1
Hz: 60
Rotation: REV
RPM Range: 1075
NEMA Frame Size: 56Z
Phase: Single
Standards: UR/CSA
FLA: 6.7-6.8/3.4
Bearing: Ball
Lead Length (in.): 30
Thermal Protection: Auto
Ambient Deg C: 65
Ins. Class: B
Shaft Dia. (in.): 5/8
Capacitor Included: No
Shaft Length (in.): 4
Capacitor Rating: 25/370 Oval
Replaces: 5KCP49UG1007S, 5KCP49UG1027S, 5KCP49UG1028S, 5KCP4
Service Factor: 1.0
Duty: Continuous
Weight: 40.0500 lbs
Harmonized Tariff Code: 8501400000
