Sauermann SI10UL02UN23 – Si-10 Mono-Bloc Condensate Removal Pump (5 GPH) 230 V
Product Overview:
The Sauermann Si-10 SI10UL02UN23 is a compact, high-performance mono-bloc condensate removal pump designed for modern HVAC and mini-split systems. With a 5 GPH flow rate and a 33 ft discharge head, it offers reliable performance for units up to approximately 5.5 tons. The Si-10 features integrated detection, quiet operation, and a compact footprint—making it ideal for installations in tight mechanical spaces such as wall-mounted or ceiling-suspended units.
Key Features & Benefits:
- High Flow Rate: Up to 5 GPH (19 L/h) for effective condensate removal.
- Strong Lift Capability: Pumps up to 33 ft (10 m) vertically.
- Quiet Performance: Approximately 22–23 dBA at 1 meter for minimal noise.
- Integrated Detection System: Built-in float control simplifies installation and improves reliability.
- Compact Mono-Bloc Design: Single-piece construction with minimal components.
- 230 V Operation: Optimized for international and high-voltage systems.
- Safety & Durability: Double insulation, thermal protection, and NC safety switch (8 A resistive – 250 V).
- Complete Kit: Includes anti-vibration bracket, power cable, vent tube, and fittings.
Technical Specifications:
- Model: SI10UL02UN23
- Voltage: 230 V ~ 50/60 Hz
- Power Consumption: 14 W
- Flow Rate: Up to 5 GPH (19 L/h)
- Max Discharge Head: 33 ft (10 m)
- Sound Level: 22–23 dBA at 1 m
- Insulation Class: Double insulation
- Detection Levels: On – 23/32″ Off – 15/32″ Safety – 13/16″
- Safety Switch Rating: 8 A resistive – 250 V
- Thermal Protection: Auto reset
- Pump Type: Mono-bloc with integrated detection
- Mounting Orientation: Horizontal or vertical using anti-vibration bracket
Applications:
- Mini-split and ducted air-conditioning systems
- Ceiling-mounted units and fan coil units
- Dehumidifiers and refrigeration equipment
- Wall-mounted indoor units up to 5.5 tons
Why Choose the Si-10 from Beenimax:
At Beenimax, we supply genuine Sauermann condensate pumps with fast shipping and contractor-friendly support. The Si-10 series delivers quiet, reliable operation in a compact form that fits tight spaces without sacrificing performance. Ideal for professional HVAC installers and homeowners seeking long-lasting condensate management solutions.
At Beenimax, we supply genuine Sauermann condensate pumps with fast shipping and contractor-friendly support. The Si-10 series delivers quiet, reliable operation in a compact form that fits tight spaces without sacrificing performance. Ideal for professional HVAC installers and homeowners seeking long-lasting condensate management solutions.
