The White Rodgers 3F01-200 is a dependable 3/4" snap disc fan control engineered for accurate temperature regulation in HVAC systems. It is ideal for activating a fan when air temperature rises and deactivating it as the system cools down.Product Specifications:
Designed for use in furnaces, air handlers, and other HVAC equipment, the 3F01-200 activates fans at 200°F and shuts them off at 180°F. Its reliable “Close on Rise” function ensures consistent and safe system performance.For installations needing an adapter plate, the F6-1798 accessory is required (sold separately).Available now at Beenimax – your reliable source
- Cut-In Temperature: 200°F
- Cut-Out Temperature: 180°F
- Differential: 20°F
- Switch Action: Close on Rise
- Contact Form: SPST (Single Pole, Single Throw)
- Reset Type: Automatic
- Mounting Type: 3/4" Flanged Airstream
- Electrical Ratings:
- Inductive Load: 5.8/34.8 A at 120 VAC, 2.9/17.4 A at 240 VAC
- Resistive Load: 25 A at 120/240 VAC
- Pilot Duty: 125 VA at 120/240/277 VAC
- Dimensions: 1.23" L x 1.32" W x 0.37" H
- Certifications: UL, CSA, VDE
Designed for use in furnaces, air handlers, and other HVAC equipment, the 3F01-200 activates fans at 200°F and shuts them off at 180°F. Its reliable “Close on Rise” function ensures consistent and safe system performance.For installations needing an adapter plate, the F6-1798 accessory is required (sold separately).Available now at Beenimax – your reliable source
